Approach
CRISP-DM, Cross-Industry Standard Process for Data Mining, was developed in the late 1990s by a consortium of NCR, SPSS, Daimler-Benz and OHRA and published in 2000 as CRISP-DM 1.0. It describes a data science project as a cycle of six phases and has been the most widely used methodology in the field ever since. Twentynext works with the ten steps of IBM’s Foundational Methodology for Data Science, which builds on it.
Get in touch →
Methodology
The original CRISP-DM has six phases. In practice we work with the ten steps of IBM’s Foundational Methodology for Data Science: the same six phases, complemented by four steps that CRISP-DM does not name as phases of their own: Analytic Approach, Data Requirements, Data Collection and Feedback. And the arrows do not only run forward: six return loops are part of the model. Below you will find, for each phase, what happens, what it delivers and where it goes wrong in practice.
1
step 1 of 10
The project does not start with the data but with the decision it is meant to improve. We establish which business goal the project serves, how success will be measured and who will work with the outcome. Skip this phase and the model can succeed while nothing changes in the organisation.
+ · steps 2–4 of 10 · added by the IBM methodology
Which kind of analysis fits the question: predicting, explaining, detecting or optimising. In the model this step comes before data exploration, while in practice you often only know which analysis fits after a first exploration. Knowing that, you plan the loop instead of being caught out by it.
What data that analysis needs: sources, format, period and quality.
How that data comes in, what is missing and what may not be used. If collecting reveals that the requirements are off, they are revised: the loop back to Data Requirements.
2
step 5 of 10
The first confrontation with the real data: how complete, how current and how reliable is it, and does it mean what everyone assumes it means? Assumptions fail in this phase, and that is the point: better in week three than after go-live. If data turns out to be missing, the loop takes you back to Data Collection.
3
step 6 of 10
Usually the largest item in the project budget: joining sources, fixing errors, building features and recording every operation so it stays reproducible. What is done well here pays off in every later phase; what is missing here you pay for later, and then the loop back to Data Collection fetches new data after all.
4
step 7 of 10
Only now does the modelling start. We train and compare several candidates against the measure from phase one, from simple to complex: the simplest model that answers the question wins. Modelling and preparation alternate: every intermediate result feeds back into data preparation. In our projects the model itself is rarely the risk; the phases before and after it are.
5
step 8 of 10
Two questions, in this order: does the solution answer the business question from phase one, and do the results hold up on data the model has not seen? This is where the decision is made: to production, back to Modeling via the return loop, or stop. Stopping is an outcome too; better here than in production.
6
step 9 of 10
Where most data projects run aground: from working experiment to a system that runs in day-to-day operations, with monitoring, documentation and an owner. This is what Twentynext is built for: our Service & Maintenance practice keeps what we build running.
+ · step 10 of 10 · added by the IBM methodology
After go-live the real measurement starts: is the system being used, are the predictions still right and is reality shifting under the model? The answers loop back to Modeling: adjust, redeploy, and the system does not quietly grow stale.
The order is not strict: as soon as the findings give reason to, you return to an earlier phase. What that looks like in practice is in our cases and projects.
CRISP-DM describes how we run a single data project. If you are looking for the route by which your whole organisation starts making decisions based on data, start at Data-driven working.
Overview
What each phase has to deliver according to the original methodology, CRISP-DM 1.0. The four steps Twentynext adds are described above, with the phases.
| Phase | Purpose | Deliverables according to CRISP-DM 1.0 |
|---|---|---|
| 1. Business Understanding | Establish which business objective the project serves and how success will be measured | Business objectives and success criteria, situation assessment, data mining goals, project plan |
| 2. Data Understanding | Collect, describe, explore and quality-check the available data | Initial data collection report, data description, data exploration, data quality report |
| 3. Data Preparation | Build the dataset the modelling will run on | Dataset and its description: selection, cleaning, derived attributes, integration, formatting |
| 4. Modeling | Select techniques, build models and assess them against each other | Modelling technique, test design, models, model assessment |
| 5. Evaluation | Check whether the result answers the business question and whether the process was sound | Assessment of results, approved models, process review, list of possible actions, decision on deployment |
| 6. Deployment | Put the result into use and keep it in use | Deployment plan, monitoring and maintenance plan, final report, project review |
The original publications, for anyone who wants to read the methodology at its source.
CRISP-DM stands for Cross-Industry Standard Process for Data Mining. The methodology was developed in the late 1990s by a consortium of NCR, SPSS, Daimler-Benz and OHRA, published in 2000 as CRISP-DM 1.0 (Chapman et al., 2000), and has been the most widely used methodology for data science projects ever since. It describes a data project as a cycle of six phases, from understanding the business question to putting the solution into use.
Business Understanding, Data Understanding, Data Preparation, Modeling, Evaluation and Deployment. The order is not strict: as soon as the findings give reason to, you return to an earlier phase.
We follow IBM’s Foundational Methodology for Data Science, which builds on CRISP-DM. Four steps that sit inside CRISP-DM’s existing phases get a place of their own there: which kind of analysis the question calls for, which data that requires, how it comes in, and what happens to the results after delivery. Those four often decide the outcome.
Complex data projects of any size. The methodology starts from the business objective, only ends at implementation, supports several iterations and is not tied to any industry.
That is when the Feedback step begins: measuring whether the system is used, whether the predictions still hold and whether reality is shifting under the model. Our Service & Maintenance practice is set up for exactly this: monitoring, maintenance and further development, so the system keeps performing in production.
